| Part Number (P/N) |
M1PA08501-CM
|
| INTERFACE |
- USB 3.2 Gen 1
- MIPI Tx D-PHY x2
|
| POWER |
DC 12v
|
| POWER CONSUMPTION |
6w
|
| VIDEO OUTPUT |
- 3840x1920@30fps
- 3840x896@30fps
- 1696x7200@15fps
|
| CONTROL |
USB Video Class (UVC) compliant
|
| OPTICAL FEATURES |
360° (Horizontal) x 85° (Vertical) field of view F2.5 aperture 1/2.7" 5M CMOS sensor x4
|
| AUDIO |
N/A
|
| PHYSICAL FEATURES |
- 78 x 75 x 86 mm
- Approximately 350 g
|
| TEMPERATURE |
- Operating Temperature: 0°C to 50°C
- Storage Temperature: -20°C to 60°C
|
| HUMIDITY |
N/A
|
| MOUNTING NOTE |
Cupola360 does not provide a standard physical base for RX1050P.
(A 3D printing file is available so customers can print and customize the mounting base according to their own platform, enclosure, or mechanical design requirements.)
|
